PRODUCT DESCRIPTION:
NR-231016 is a 24V starter motor delivering 4 kW of power, equipped with a 10 teeth pinion and clockwise rotation (CR). Designed for industrial truck applications, it offers a durable structure and seamless performance with 89 mm Size A, 48 mm drive distance, and a total length of 315 mm. Featuring 3 mounting holes and no threaded holes, this unit is extensively used in Iveco Eurocargo vehicles with Tector engines.

Technical Specifications
Voltage: 24V
Power: 4 kW
Number of Teeth: 10
Rotation: CR (Clockwise)
Size A: 89 mm
Drive Distance: 48 mm
Drive Diameter (Outer): 39 mm
Number of Mounting Holes: 3
Number of Threaded Mounting Holes: 0
Length: 315 mm

Reference Numbers (Crosses)
Bosch: 0001231016, 0001251009, 0001251010, 0001263021, 0001263022, 0986020170, 0986022400, 1986S10040, F042002088
Cargo: 112498
CAS: CST10664, CST10664AS, CST10664ES, CST10664OS, CST10664RS, CST10773, CST10773AS, CST10773ES, CST10773OS, CST10773RS
CASE: 4892338
Cummins: 4892338
Delco Remy: 19083029
Ghibaudi: JB243708145
HC-PARTS: CS1268
HELLA: 8EA012586521
Iskra: 11131501, AZF4646, IS1277
Iveco: 04892338, 1231016, 1892338, 2995382, 2995986, 42498718, 48922338, 4892338, 489233800, 500059586, 5801381129, 5801577135
KRAUF: STB1268AB, STB1268BA, STB1268LC, STB1268MA, STB1268MH, STB1268NB, STB1268SU, STB1268TJ, STB1268UL, STB1268UW, STB2510ML, STB5268MN, STB6268UL, STB9368UL, STP1268MH
Magneti Marelli: 063522310160, 063721268010, MQS1268, MSN2008
Messmer: 220512
Motorherz: STB1268RB, STB1268WA, STB6268WA
New Holland: 4892338
Nissan: 23300LA4MA
Prestolite: 860716, M93R3059SE, M93R3059SE-VPP
Unipoint: STR2315
Valeo: 458332
WPS: 30123N
ZAUFER: 300N10060Z

Application
IVECO 100 E 17 (3.9 Tector) [F4AE0481A] – from 09.2000
IVECO 100 E 18 (5.9 Tector) [F4AE0681E] – from 09.2000
IVECO 100 E 21 (5.9 Tector) [F4AE0681D] – from 09.2000
IVECO 120 E 18 (5.9 Tector) [F4AE0681E] – 09.2000 to 08.2003
IVECO 120 E 24 (5.9 Tector) [F4AE0681B] – from 09.2000
IVECO 120 E 28 (5.9 Tector) [F4AE0681A] – from 09.2000
IVECO 120 EL 17 (3.9 Tector) [F4AE0481A] – from 09.2000
IVECO 120 EL 21 (5.9 Tector) [F4AE0681D] – from 09.2000
IVECO 130 E 18 / 24 / 28 (5.9 Tector) – from 09.2000
IVECO 140 E 18 / 24 (5.9 Tector) – from 09.2000
IVECO 150 E 18 / 24 / 28 (5.9 Tector) – from 09.2000
IVECO 180 E 21 / 24 / 28 (5.9 Tector) – from 09.2000
IVECO 320 E 28 (5.9 Tector) – from 09.2000
IVECO 65 E 13 / 15 (3.9 Tector) – 09.2000 to 08.2003
IVECO 75 E 13 / 15 / 17 / 18 (3.9 / 5.9 Tector) – 09.2000 to 08.2003
IVECO 80 E 15 / 17 / 18 / 21 (3.9 / 5.9 Tector) – 09.2000 to 08.2003
IVECO 90 E 17 / 18 / 21 (3.9 / 5.9 Tector) – 09.2000 to 08.2003
IVECO EUROCARGO 120 E 20 CNG – from 2006
