PRODUCT DESCRIPTION:
NR-8200699 starter motor operates at 24V with 8.2 kW power and 11 teeth. Designed for clockwise rotation (CR), this model features an L-type bolt terminal and no vacuum pump. It is compatible with various CUMMINS 8.3L ISC, ISM, ISX engines and BMC Prof 39MT vehicles.

Technical Specifications

• Voltage: 24V

• Power: 8.2 kW

• Number of Teeth: 11

• Rotation: Clockwise (CR)

• Size A: 92 mm

• Drive Distance: 47 mm

• Drive Diameter (Outer): 55 mm

• Number of Mounting Holes: 3

• Number of Threaded Mounting Holes: 0

• Length: 358 mm

Application
CUMMINS VARIOUS MODELS 8.3L ISC, ISM, ISX
BMC Prof 39MT

Cross Reference Numbers
Cargo: 114331, F032114331
CAT: 2071564, 3T3152
CUMMINS: 147923, 3102765, 3103952, 3899973, ST2001, ST2018, ST7029, ST8007, ST8018
Delco Remy: 8200009, 8200699, 8200720, 8200321, 8300016, 61003202
Mitsubishi: M9T82471, M9T82479, M009T82471, M009T82479
KRAUF: STM4331MH, STM4331NB, STM4331NL, STM4331ZL, STD4331
Motorherz: STM4331RB, STM4331WA
PAPA: 510076
Unipoint: STR4390, STR4390B, STR4390D, STR4392, STR4392B
WAI: 2-2824-MI, 2-3322-2W, 19535N, 19535R
WPS: 19535N
ZAUFER: 300N10691Z
SEPRESTOLITE: M105R3508SE, M105R3532SE
KUHNER: 254589, 254589P, 254759, 254759D, 254759P, 254887D, 254887P
EFFE: STRS4013
GSCASCO: CST60612
DIXIE: S-80131
ELECTROLOG: STR2173
GHIBAUDI: SG0211
REAL: 20409216
SANDO: 6060612
SIOM: MAV626120, MAV626130
STARDAX: STX201301
WILSON: 91-27-3306, 91-27-3306N
WOODAUTO: STR71223
Remark: STR7212, STR4390
